SPESIFIKASI TOYOTA
SPESIFIKAS ALPHARD
|
Overall Panjang / Length |
4915 |
|
Overall Lebar / Width |
1850 |
|
Overall Tinggi / Height |
1895 |
|
Jarak Poros Roda / Wheelbase |
3000 |
|
Jarak Pijak / Tread (Depan / Front) |
1575 |
|
Jarak Pijak / Tread (Belakang / Rear) |
1570 |
|
Jarak Terendah / Ground Clearance |
160 |
|
Radius Putar / Turning Radius |
– |
|
Berat Kosong / Cub Weight |
– |
|
Transmisi / Transmission Type |
CVT |
|
Perbandingan Gigi / Gear Ratio 1st |
2.517 – 0.390 |
|
Perbandingan Gigi / Gear Ratio 2nd |
2.517 – 0.390 |
|
Perbandingan Gigi / Gear Ratio 3rd |
2.517 – 0.390 |
|
Perbandingan Gigi / Gear Ratio 4th |
2.517 – 0.390 |
|
Perbandingan Gigi / Gear Ratio 5th |
2.517 – 0.390 |
|
Perbandingan Gigi / Gear Ratio 6th |
2.517 – 0.390 |
|
Perbandingan Gigi / Gear Ratio 7th |
– |
|
Perbandingan Gigi Mundur / Gear Ratio Reverse |
2.517 – 0.696 |
|
Perbandingan Gigi Akhir / Gear Ratio Final |
5.791 |
|
Suspensi Depan / Front Suspension |
MacPherson Strut with Torsion Bar |
|
Suspensi Belakang / Rear Suspension |
Double Wishbone with Torsion Bar |
|
Rem Depan / Front Brake |
Ventilated Disc |
|
Rem Belakang / Rear Brake |
Ventilated Disc |
|
Sistem Rem Tambahan / Additional Brake System |
– |
|
Steering Gear |
Rack and Pinion with EPS |
|
Ukuran Ban / Tire Size |
235/50/R18 |
|
Seri Mesin / Machine Serial |
2AR-FE |
|
Tipe Mesin / Engine Type |
2AR-FE, In-Line 4 Cylinder, 16-Valve, DOHC, Dual VVT-i |
|
Isi Silinder / Displacement (cc) |
2,494 |
|
Diameter X langkah / Bore X Stroke (Mm) |
90.0 x 98.0 |
|
Daya Maksimum / Maximum Output (Ps/Rpm) |
180/6,00 |
|
Torsi Maksimum / Maximum Torque (Kgm/Rpm) |
23.9/4,100 |
|
SistemPemasukan Bahan Bakar / Fuel System |
EFI |
|
Bahan Bakar / Fuel |
– |
|
Kapasitas Tangki / Fuel Capacity |
75 |
|
Steering (Power Steering) |
– |
